    Dry Riser Inlet Vertical Cabinet


    Dry Riser Inlet Vertical Cabinet – manufactured to BS5041 house the inlet breaching valve, these valves, connected via pipe work, allow the initial connection to the dry riser system. They feed the dry riser outlets sited within outlet cabinets on each floor of the building.

    • Colour: Red RAL3002 or Stainless
    • Height: 595mm
    • Width: 395mm
    • Depth: 295mm
    • Cabinet and Door: 16swg Zintec Steel or Stainless, Satin Polished
    • Architrave: 30mm Wide All Round
    • Glass: Yes
    • Lettering: PRV
    • Lock: Slam Lock with Key
    • Hinge: Stainless Steel
    • Hinge Type: Piano
    • Standard: BS5041 : Part 4
    • Aperture: 605(High) x 405(Wide) x 305(Deep) mm

    Options

    LK/10905502…16SWG Zintec Steel, Red RAL3002
    LK/10905506…16 SWG Stainless Steel, Satin Polished
