Landon Kingsway’s reliable and robust high level float switch is used in conjunction with the Filguard alarm panel to provide an early warning for the tanker driver to stop filling, preventing unwanted overfill of the tank and oil pollution / spill.
The float switch requires no power and has no adjustable parts. The switch mechanism relies on the stainless steel sealed float being raised by the liquid in the tank when near full. When the liquid level falls the float falls by gravity.
Part Number (Standard Version): 40901211
Optional – Extended rod versions available tailored to your requirements
.
Mounting : 1″ BSP
Liquid Switch Point (Standard) : 250mm below thread end (depending on s.g. of liquid)
Protection : IP65 / IP68
Materials : Stainless Steel Float, Aluminium Housing
