TechnoControl SE294K Gas detection control unit with display for 3 remote sensors

Introducing the SE294K Control Unit, a sophisticated solution designed for monitoring three remote sensors with unparalleled precision. Each central panel hosts LED bars that vividly depict gas concentrations, with green indicating fresh air, dual red LEDs signalling pollution, and a distinct setup for activating the alarm relay. The yellow LED ensures immediate anomaly detection, triggering the fault relay for swift action. Enhancing user interface, a graphic backlit display provides comprehensive insights. This unit accommodates mixed sensor inputs for Natural Gas, LPG, and CO₂, fostering adaptability and versatility.

Product overview

Graphic backlighted Display.
3 inputs for sensors – Natural gas / LPG / CO₂ sensors connected can be mixed between NG – LPG / CO₂
N° 3 relay outputs for alarm and fault with alarm memory. Alarm levels (relays) programmable via DIP-Switch.
N° 2 AUX inputs for Solenoid valve with CPI control position and Emergency Push Button.
TEST & RESET function.
Degree of protection IP65.
Designed According to EN50054-50057.

Specification

Code	Gas Detected	Installation	Sensor type	Measuring Range	Alarm Intervention	Power Supply
SE294K	Natural Gas LPG CO₂	Wall	SE192KM SE192KG SE193KM SE193KG	0÷20% LEL	10% LEL 20% LEL	110 / 230Vac 50/60Hz 12Vdc (-15/+10%)
