TechnoControl CE408 Control unit for 4 - 8 sensors

TechnoControl CE408 Control unit for 4 – 8 sensors

Introducing the CE408 Gas Detection Control Unit, an ideal solution tailored for small gas detection systems, delivering top-notch performance. Designed for efficiency, this unit accommodates 4 to 8 sensors, making it versatile for various setups. Its standout feature—a large, backlit display on the front panel—provides real-time visualisation of all sensor readings, ensuring prompt and accurate monitoring. With 4 inputs and 5 relays as standard, expandability to 8 detectors and 9 output relays is achievable through dedicated expansion boards. The user-friendly keyboard offers intuitive control, while the system’s self-driving capability and pre-configured detectors streamline programming, ensuring ease of use and enhanced efficiency in gas detection operations.

Product overview

Compatible to all sensor’s series “SE” and “TS” with output 4-20mA and RS485 only for CE516 /532.
RS485 to connect max. n° 2 CE380UR remote units.
Easy setup with pre-configurated list of pre-programmed detectors.
Configuration protected by a password (3 safety levels).
AND, OR and PARKING (EN50545-1) logical operation usable in zones.
Operation/Working visualization with backlighting display.
SD Card for: Firmware updating, Data logger & Programming backup.

Specification

Code	Installation	Connectable sensors	Measuring Range	Power Supply	Output	Capacity
CE408P	Wall	Series ”TS” and “SE” (max 8 with expansion)	Programmable	110/230 Vac (-15% + 10%)	5 Relays (max 9 with ES414)	3A(1A) SPDT 230Vac
CE516P	Wall	Series “TS” and “SE” (max 16)	Programmable	110/230 Vac (-15% + 10%)	5 Relays (max 17 with ES414)	3A(1A) SPDT 230Vac
CE424P	Wall	Series “TS” and “SE” (max 24 with 2 CE380UR)	Programmable	110/230 Vac (-15% + 10%)	5 Relays (max 25 with ES414)	3A(1A) SPDT 230Vac
CE532P	Wall	Series ”TS” and “SE” (max 32 with 2 CE480UR)	Programmable	110/230 Vac (-15% + 10%)	5 Relays (max 33 with ES414)	3A(1A) SPDT 230Vac
